Aluminium Al-Si10Mg
- Alternative Designations: EN - 1706
Description:
This material has excellent strength at elevated temperatures (about 200°C). It has good resistance to corrosion and can be polished easily. It has good workability and good heat crack resistance. The fatigue strength is excellent at 110N/mm2. The material has good weldability and is widely applied in parts for vehicles, machines, and aircraft. It has a tensile strength of 454 – 474MPa at room temperature.
Material Properties
Processes:
Special properties
- Strength
- Heat resistance
- Corrosion resistance
- Weldability
- Thermal conductivity
- Electrical conductivity
Property | Value, metric | Value, Imperial |
---|---|---|
Density | 1.07 g/cm3 | 1.07 g/cm3 |
Elongation at Break | 6-8% | 6-8% |
Hardness | 124 | 124 |
Ultimate Tensile Strength | 450 MPa | 65 ksi |
-
CNC machined part without surface finishes (3D render, aluminium)Bead blasting (3D render)
Bead blasting
Bead blasting involves spraying a pressurised stream of tiny beads of media, plastic or glass beads, from a nozzle onto the surface of the part. This removes the burrs and imperfections, leaving a smooth finish.
Notes:The recommended part size is 6-600 mm in both height and width. Smaller parts are hard to hold and tough to produce an even surface.
Final result:
- Uniform, matte or satin-like appearance
- Slightly grainy in the touch
-
Custom Finishing
If you select a custom finish in the Instant Quoting Engine it will require manual review. Manual quoting usually takes 1-2 business days.
Notes:Submitting for manual review with a custom request does not guarantee a quote.
